Smart choice for any workplace
9,900 THB
- Print up to 63mm RD rolls width
- USB and Serial connection
- Tear Bar
- Print Labels, Receipts, and Wristbands
- Compatible with customised media
- Optional accessories available
Information
Overview
Basic Specs
Available Tape Widths
Up to 63mm
Dimension (Width x Depth x Height)
110 mm x 215 mm x 172 mm
Weight
1.32 kg
Warranty
1 year
Print Output
Print Resolution
203 dpi
Print Speed
Maximum 6 ips (152.4 mm/sec) (Under Brother standard environment)
Bar Code
21 barcode protocols on P-touch Editor 5.1
Functions
Cutter
Die-cut labels / Tear off
Mirror Printing
Yes
Memory
File Storage
Max 99 templates
Memory Buffer Size
6MB
Power Supply
Power Supply
100 - 240 V 50/60 Hz
AC Adaptor
Included
Interface
Button
(Power) button, (Feed) button, (Print) button
Display
SVGA/High Color or more
Connectivity
USB
USB Ver.2.0 (Full Speed) (mini-B, Peripheral)
Specifications
Basic Specs
Keyboard
No Keyboard
Display Type
No
Media Type
Continuous Receipt roll - (Non-coated or Coated), Continuous or Die-cut Labels, Wristband, Tag
Available Tape Widths
Up to 63mm
Product Dimensions (Width X Depth X Height)
110 mm × 215 mm × 172 mm
Weight
1.32 kg
Print Speed
152.4 mm/sec (6ips)
Resolution
203 dpi
No. Of Printable Lines
Adjustable within 63mm width
Number of Characters
No
Number of Symbols
No
Barcode
1. CODE 39
2. CODE 128
3. CODE 93
4. CODABAR (NW-7)
5. ITF (I-2/5)
6. UPC-A
7. UPC-E
8. UPC and EAN 2 or 5-digit extensions
9. EAN-8 (JAN-8)
10. EAN-13 (JAN-13)
11. GS1-128 (UCC/EAN-128)
12. GS1 DataBar（RSS14、RSS14 Stacked、RSS14 Truncation、RSS14 Stacked Omnidirection）,（RSS Limited）, （RSS Expanded, RSS Expanded Stacked）
13. MSI
14. POSTNET
15. PDF417 (Standard, Truncate, MicroPDF417)
16. Data Matrix (ECC200 Square, ECC200 Rectangular)
17. Maxicode
18. QR Code (model 1, model 2, Micro QR),
19. Aztec
Numbering
Print via P-touch Editor
Connectivity
Connectivity
USB version 2.0 (Full Speed) (mini-B)
Media
Maximum Roll Width
63mm
Printing Width
Up to 56 mm
Functions
Cutter
No cutter, Tear off
Multi Block Printing
Print via P-touch Editor
Copy Printing
Print via P-touch Editor
Mirror Printing
Print via P-touch Editor
Preview
via P-touch Editor
Memory
File Storage
6 MB or Maximum 99 templates
Memory Buffer Size
20MB
Power
Power Source
100 - 240 V 50/60 Hz
Auto Power-Off
Yes
Supported Commands
Supported Commands
P-touch Template2.0 , ZPLII compatible, Raster, ESC/P, CPCL compatible
